10-Ton Dual-Configuration (Horizontal & Vertical) Keyway Broaching Machine Series

Product Description

The 10-Ton Keyway Broaching Machine Series is a versatile and robust manufacturing solution engineered for high-precision keyway machining. Uniquely available in both horizontal and vertical configurations, this series empowers manufacturers to optimize workshop space and seamlessly process diverse workpiece geometries, from long shafts to compact flanges. Delivering a highly stable 10-ton (100 kN) pulling force, the machine is built on a high-rigidity cast iron bed and driven by an advanced PLC control system. It guarantees exceptional dimensional accuracy, tight tolerances, and efficient automated cycling, making it the ideal choice for high-volume production of gears, pulleys, couplings, and motor shafts.

Key Features & Advantages

1. 70% Energy Savings & ISO 1328 Grade 5/7 Precision

Unlike traditional hydraulic broaching machines, our advanced drive system reduces energy consumption by up to 70%, significantly lowering your long-term operational costs. Meanwhile, the high-rigidity structure and high-speed cutting capability guarantee exceptional gear precision up to ISO 1328 Grade 5/7. This makes it a highly efficient and cost-effective alternative to costly gear grinding processes.

2. Versatile Dual-Configuration Design (Horizontal & Vertical)
This 10-ton series offers both horizontal and vertical layouts to perfectly match your production needs. The horizontal model is ideal for processing long shafts and heavy components with stable support, while the vertical model optimizes factory floor space and is perfect for disc-like, flange, or short-axis parts. This dual-layout flexibility allows you to maximize your workshop's spatial efficiency.

3. Turnkey & Customizable Solutions for Unique Needs

We understand that every gear manufacturing project is unique. Beyond our standard models, we offer comprehensive tailor-made services. Whether you need specific fixture designs, specialized carbide broaching tools, or custom automated loading/unloading systems, our engineering team will build a solution strictly according to your special requirements.
